Media Kit
Mohr and Associates
CT100 Series Automated Metallic TDR Cable Testers and CT Viewer™ TDR Waveform Analysis Software
CT100/CT100HF Automated Metallic TDR Cable Tester Datasheet
Frontal view of CT100HF (2606x1439, 300 DPI)
Frontal view of CT100 (841x457, 96 DPI)
Left oblique view of CT100HF (1334x780, 300 DPI)
CT100 screenshot -- Identifying a loosened interconnect, a subtle partial cable fault (487x275, 72 DPI). Live and saved traces with tightened connector (black, green), saved trace with slightly loosened connector (purple), difference between loosened and tightened connector normalized to 50 Ohms (blue). The operator can save and recall thousands of high resolution waveforms.
CT100 screenshot -- Measuring a 1000 Ohm termination at the end of a 575 ft. nominal 50 Ohm cable with 0.5% accuracy (482x275, 72 DPI). The inactive cursor (dashed vertical red line) is at the end of the 575 ft. cable and the active cursor (solid vertical red line) is positioned such that the reflection from the 1000 Ohm termination has stabilized. The measured value reads within 0.5% of the true value.
CT Viewer screenshot -- Comparing cable lengths at 4 mm per major division (1680x1003, 72 DPI). The CT100 and CT Viewer are capable of precision length measurements of as little as 75 microns in standard coaxial cable (VoP=0.66).
